Assure
Stylish and versatile
The Assure panel is doubly versatile: it can be installed with either a smooth top-rail or, simply by turning it upside down, with the verticals extending above the rail, making specifying for both safety and security easy.
Whatever the orientation, Assure is ideal for school and childcare environments and residential applications, and is strong and robust, delivering years of maintenance-free security.
-
- Application
- Residential, Retirement Villages, Multi-unit Residential
-
- Material
- Aluminium
-
- Height
-
Ex-stock at 1200mm, 1500mm, 1750mm H (4 horizontal rails)
-
- Width
-
Ex-stock at 2400mm W
Widths up to 2400mm W can be achieved by cutting the width of the panel down
-
- Profiles
-
• 19x19mm aluminium vertical bar
• 80mm gap between verticals
• 38x25mm horizontal rails
-
- Colours
-
Ex-stock satin black
Custom colour available on request
-
- Posts
-
• 65x65x2mm aluminium post up to 2500mm L
• 65x65x3mm aluminium base plated post up to 2000mm L
-
- Post Centres
-
Up to 2465mm W
-
- Gates
-
Ex-stock width adjustable pedestrian gates
• 1200mm H x 1170mm W
• 1500mm H x 1170mm W
• 1750mm H x 1170mm W
Ex-stock width adjustable double swing driveway gates
• 1200mm H x 4000mm W
• 1500mm H x 4000mm W
• 1750mm H x 4000mm W
Custom sizes on request
-
- Pool Compliant
-
Yes
-
- Balustrade Compliant
-
Yes
-
- Raking Panels Available
-
Yes - up to 30 degrees
Residential and pool fencing
Balustrade and retaining wall barriers
Childcare/schools
Cycleways/civil fencing
Strong, robust construction
Lightweight, easy to install
Can be flipped vertically for versatile use
Exclusively available as raking panel up to 30 degrees
Colour options
Satin black or custom colour available on request
Product downloads
Product enquiry
If you’re looking for specific product information, complete the form and we will be in touch within the next business day. For urgent enquiries, call our team on 0800 80 3326 or email sales@urbangroup.co.nz.
